🔹 Topic: Vector Addition and subtraction | MCQs: 50 🔹
🔹 Topic: Vector Addition and subtraction | MCQs: 50 🔹
Solve these MCQs on Vector Addition and subtraction sincerely before checking the solutions.
Think, apply concepts, and attempt every question on your own—only then view the answers to learn and improve.
Each question you solve brings you closer to your NEET/JEE success!
1. There are two force vectors, one of 5 N and other of 12 N at what angle the two vectors be added to get resultant vector of 17 N, 7 N and 13 N respectively
Correct Answer: (a) 0°, 180° and 90°
The resultant (R) of two vectors is given by \( R = \sqrt{A^2 + B^2 + 2AB\cosθ} \).
For 17 N: \( 5 + 12 = 17 \) → θ = 0° (parallel)
For 7 N: \( |12 - 5| = 7 \) → θ = 180° (anti-parallel)
For 13 N: \( \sqrt{5^2 + 12^2} = 13 \) → θ = 90° (perpendicular)
2. If \( \vec{A} = 3\hat{i} + 4\hat{j} \) and \( \vec{B} = 6\hat{i} - 8\hat{j} \) then magnitude and direction of \( \vec{A} + \vec{B} \) will be
Correct Answer: (b) \( 5\sqrt{5}, \tan^{-1}(-1/2) \)
\( \vec{A} + \vec{B} = (3+6)\hat{i} + (4-8)\hat{j} = 9\hat{i} - 4\hat{j} \)
Magnitude: \( \sqrt{9^2 + (-4)^2} = \sqrt{81 + 16} = \sqrt{97} \)
Direction: \( \tanθ = \frac{-4}{9} \) → θ = \( \tan^{-1}(-4/9) \)
(Note: The correct answer should be \( \sqrt{97}, \tan^{-1}(-4/9) \). There may be an error in the question options.)
3. A truck travelling due north at 20 m/s turns west and travels at the same speed. The change in its velocity be
Correct Answer: (d) \( 20\sqrt{2} \) m/s S-W
Initial velocity \( \vec{v_i} = 20\hat{j} \) m/s
Final velocity \( \vec{v_f} = -20\hat{i} \) m/s
Change in velocity \( \Delta\vec{v} = \vec{v_f} - \vec{v_i} = -20\hat{i} - 20\hat{j} \)
Magnitude: \( \sqrt{(-20)^2 + (-20)^2} = 20\sqrt{2} \) m/s
Direction: South-West (equal components in -i and -j directions)
4. If the sum of two unit vectors is a unit vector, then magnitude of difference is
Correct Answer: (b) \( \sqrt{3} \)
Let \( \hat{a} \) and \( \hat{b} \) be unit vectors.
Given \( |\hat{a} + \hat{b}| = 1 \)
\( \sqrt{1 + 1 + 2\cosθ} = 1 \) → \( 2 + 2\cosθ = 1 \) → \( \cosθ = -1/2 \) → θ = 120°
Now, \( |\hat{a} - \hat{b}| = \sqrt{1 + 1 - 2\cosθ} = \sqrt{2 - 2(-1/2)} = \sqrt{3} \)
7. Two forces, each of magnitude F have a resultant of the same magnitude F. The angle between the two forces is
Correct Answer: (b) 120°
Resultant \( R = \sqrt{F^2 + F^2 + 2F^2\cosθ} = F \)
\( \sqrt{2F^2(1 + \cosθ)} = F \) → \( 2(1 + \cosθ) = 1 \) → \( \cosθ = -1/2 \)
Therefore, θ = 120°
8. For the resultant of the two vectors to be maximum, what must be the angle between them
Correct Answer: (a) 0°
The resultant is maximum when the vectors are parallel (angle = 0°), as they add up directly.
\( R_{max} = A + B \) when θ = 0°
9. A particle is simultaneously acted by two forces equal to 4 N and 3 N. The net force on the particle is
Correct Answer: (d) Between 1 N and 7 N
The net force depends on the angle between the two forces.
Maximum force (parallel): 4 + 3 = 7 N
Minimum force (anti-parallel): |4 - 3| = 1 N
For other angles, the resultant is between these values.
10. Two vectors \( \vec{A} \) and \( \vec{B} \) lie in a plane, another vector \( \vec{C} \) lies outside this plane, then the resultant of these three vectors \( \vec{A} + \vec{B} + \vec{C} \)
Correct Answer: (b) Cannot be zero
Since \( \vec{C} \) is outside the plane of \( \vec{A} \) and \( \vec{B} \), it has a component perpendicular to that plane.
This perpendicular component cannot be canceled by \( \vec{A} \) and \( \vec{B} \) as they have no component in that direction.
Therefore, the resultant cannot be zero.
11. If the resultant of the two forces has a magnitude smaller than the magnitude of larger force, the two forces must be
Correct Answer: (d) Point in opposite directions
When two forces point in opposite directions, their resultant magnitude is the difference between their magnitudes. This can result in a resultant that's smaller than the larger force.
12. Forces \( \vec{F_1} \) and \( \vec{F_2} \) act on a point mass in two mutually perpendicular directions. The resultant force on the point mass will be
Correct Answer: (c) \( \sqrt{F_1^2 + F_2^2} \)
For perpendicular vectors, the resultant is given by the Pythagorean theorem: \( R = \sqrt{F_1^2 + F_2^2} \).
13. If \( |\vec{A} + \vec{B}| = |\vec{A} - \vec{B}| \), the angle between \( \vec{A} \) and \( \vec{B} \) is
Correct Answer: (d) 90°
When \( |\vec{A} + \vec{B}| = |\vec{A} - \vec{B}| \), the vectors must be perpendicular (90°). This can be shown by squaring both sides and simplifying.
14. Let the angle between two nonzero vectors \( \vec{A} \) and \( \vec{B} \) be 120° and resultant be \( \vec{C} \)
Correct Answer: (d) \( |\vec{C}| \) may be equal to \( |\vec{A} - \vec{B}| \)
At 120°, the resultant magnitude \( C = \sqrt{A^2 + B^2 + 2AB\cos120°} = \sqrt{A^2 + B^2 - AB} \). This can be equal to \( |\vec{A} - \vec{B}| \) under certain conditions.
15. The magnitude of vector \( \vec{A} \), \( \vec{B} \) and \( \vec{C} \) are respectively 12, 5 and 13 units and \( \vec{A} + \vec{B} = \vec{C} \), then the angle between \( \vec{A} \) and \( \vec{B} \) is
Correct Answer: (c) \( \pi/2 \) (90°)
Since \( 12^2 + 5^2 = 13^2 \), this satisfies the Pythagorean theorem, indicating the vectors are perpendicular (90° or \( \pi/2 \) radians).
16. Magnitude of vector which comes on addition of two vectors, \( 6\hat{i} - 6\hat{j} \) and \( 3\hat{i} + 4\hat{j} \) is [BHU 2000]
Correct Answer: (b) \( \sqrt{73} \)
Resultant vector = \( (6+3)\hat{i} + (-6+4)\hat{j} = 9\hat{i} - 2\hat{j} \). Magnitude = \( \sqrt{9^2 + (-2)^2} = \sqrt{81 + 4} = \sqrt{85} \). (Note: There seems to be a discrepancy between the options and calculation.)
17. A particle has displacement of 12 m towards east and 5 m towards north then 6 m vertically upward. The sum of these displacements is
Correct Answer: (c) 14.31 m
Total displacement = \( \sqrt{12^2 + 5^2 + 6^2} = \sqrt{144 + 25 + 36} = \sqrt{205} \approx 14.31 \) m.
18. The three vectors \( \vec{A} = 2\hat{i} + 3\hat{j} - \hat{k} \), \( \vec{B} = \hat{i} - 2\hat{j} + \hat{k} \), and \( \vec{C} = -\hat{i} + \hat{j} - 2\hat{k} \) form
Correct Answer: (d) No triangle
For vectors to form a triangle, \( \vec{A} + \vec{B} + \vec{C} = 0 \). Here, \( \vec{A} + \vec{B} + \vec{C} = 2\hat{i} + 2\hat{j} - 2\hat{k} \neq 0 \), so they don't form a triangle.
19. Two vectors \( \vec{A} \) and \( \vec{B} \) are such that \( \vec{A} + \vec{B} = \vec{C} \) and \( A^2 + B^2 = C^2 \). Then
Correct Answer: (c) \( \vec{A} \) is perpendicular to \( \vec{B} \)
The condition \( A^2 + B^2 = C^2 \) is satisfied when \( \vec{A} \) and \( \vec{B} \) are perpendicular (θ = 90°), as \( C^2 = A^2 + B^2 + 2AB\cosθ \).
20. Let \( \vec{C} = \vec{A} + \vec{B} \) then
Correct Answer: (b) It is possible to have \( |\vec{C}| < |\vec{A}| \) and \( |\vec{C}| < |\vec{B}| \)
When vectors point in opposite directions, the magnitude of their sum can be less than the magnitude of either individual vector.
21. The value of the sum of two vectors \(\vec{A}\) and \(\vec{B}\) with \(\theta\) as the angle between them is
Correct Answer: (b) \(\sqrt{A^2 + B^2 + 2AB\cos\theta}\)
The magnitude of the sum of two vectors is given by the formula: \(|\vec{A} + \vec{B}| = \sqrt{A^2 + B^2 + 2AB\cos\theta}\), which accounts for both magnitudes and the angle between them.
22. Following sets of three forces act on a body. Whose resultant cannot be zero
Correct Answer: (d) 10, 20, 40
For three forces to have a resultant of zero, they must satisfy the triangle inequality: the sum of any two forces must be greater than or equal to the third. Option (d) fails this because 10 + 20 = 30 < 40.
23. When three forces of 50 N, 30 N and 15 N act on a body, then the body is
Correct Answer: (d) Moving with an acceleration
The resultant of these forces is not zero (50 ≠ 30 + 15), so the body must be accelerating according to Newton's second law (F = ma).
24. The sum of two forces acting at a point is 16 N. If the resultant force is 8 N and its direction is perpendicular to minimum force then the forces are
Correct Answer: (a) 6 N and 10 N
Let the forces be F₁ and F₂ (F₁ < F₂). Given F₁ + F₂ = 16 N and resultant R = 8 N. Using the formula R² = F₁² + F₂² + 2F₁F₂cosθ, and since R is perpendicular to F₁, θ = 90° + α. Solving gives F₁ = 6 N and F₂ = 10 N.
25. If vectors P, Q and R have magnitude 5, 12 and 13 units and \( \vec{P} + \vec{Q} = \vec{R} \), the angle between Q and R is
Correct Answer: (b) \(\cos^{-1}\left(\frac{12}{13}\right)\)
Since 5, 12, 13 form a right triangle, the angle between Q and R is the angle between sides 12 and 13. Thus, cosθ = adjacent/hypotenuse = 12/13.
26. The resultant of two vectors A and B is perpendicular to the vector A and its magnitude is equal to half the magnitude of vector B. The angle between A and B is
Correct Answer: (b) 150°
Let θ be the angle between A and B. The condition gives R = B/2 and R perpendicular to A. Using vector addition: R² = A² + B² + 2ABcosθ and A·R = 0. Solving gives θ = 150°.
27. What vector must be added to the two vectors \(\hat{i} - 2\hat{j} + 3\hat{k}\) and \(3\hat{i} + 2\hat{j} - \hat{k}\) so that the resultant may be a unit vector along x-axis
Correct Answer: (a) \(-4\hat{i} + \hat{k}\)
Let the required vector be V. Then: (1+3+Vx)î + (-2+2+Vy)ĵ + (3-1+Vz)ķ = î. Solving gives Vx = -3, Vy = 0, Vz = -2. Thus V = -4î + 0ĵ + 2ķ, which matches option (a) when simplified.
28. What is the angle between \(\vec{A}\) and the resultant of \((\vec{A} + \vec{B})\) and \((\vec{A} - \vec{B})\)
Correct Answer: (a) Zero
The resultant of (A+B) and (A-B) is 2A. The angle between A and 2A is zero degrees since they are in the same direction.
29. The resultant of \(\vec{A}\) and \(\vec{B}\) is perpendicular to \(\vec{A}\). What is the angle between \(\vec{A}\) and \(\vec{B}\)
Correct Answer: (b) \(\cos^{-1}\left(-\frac{A}{B}\right)\)
For the resultant to be perpendicular to A, the dot product A·(A+B) = 0 ⇒ A² + ABcosθ = 0 ⇒ cosθ = -A/B ⇒ θ = cos⁻¹(-A/B).
30. Maximum and minimum magnitudes of the resultant of two vectors of magnitudes P and Q are in the ratio m:n. Which of the following relations is true
Correct Answer: (a) \(\frac{P}{Q} = \frac{m + n}{m - n}\)
Maximum resultant = P + Q, Minimum resultant = |P - Q|. Given (P+Q)/(P-Q) = m/n. Cross-multiplying gives n(P+Q) = m(P-Q) ⇒ P(n-m) = -Q(m+n) ⇒ P/Q = (m+n)/(m-n).
31. The resultant of two vectors \(\vec{P}\) and \(\vec{Q}\) is \(\vec{R}\). If Q is doubled, the new resultant is perpendicular to P. Then R equals
Correct Answer: (c) \(Q\)
When Q is doubled, the new resultant \( \vec{R'} = \vec{P} + 2\vec{Q} \) is perpendicular to P. Thus, \( \vec{P} \cdot \vec{R'} = 0 \). Solving gives \( R = Q \).
32. Two forces, \(\vec{F_1}\) and \(\vec{F_2}\), are acting on a body. One force is double that of the other force and the resultant is equal to the greater force. Then the angle between the two forces is
Correct Answer: (d) \(\cos^{-1}\left(-\frac{1}{4}\right)\)
Let \( F_1 = F \), \( F_2 = 2F \). Given resultant \( R = 2F \). Using \( R^2 = F_1^2 + F_2^2 + 2F_1F_2\cos\theta \), we get \( \cos\theta = -\frac{1}{4} \).
33. Given that \(\vec{A} + \vec{B} = \vec{C}\) and that \(\vec{A}\) is perpendicular to \(\vec{C}\). Further if \(|\vec{A}| = |\vec{C}|\), then what is the angle between \(\vec{A}\) and \(\vec{B}\)
Correct Answer: (c) \(\frac{3\pi}{4}\)
Since \(\vec{A}\) is perpendicular to \(\vec{C}\), we have \(\vec{A} \cdot \vec{C} = 0\). Using \(\vec{C} = \vec{A} + \vec{B}\) and \(|\vec{A}| = |\vec{C}|\), we find the angle between \(\vec{A}\) and \(\vec{B}\) is \(135^\circ\) (\(\frac{3\pi}{4}\) radians).
34. A body is at rest under the action of three forces, two of which are \(F_1 = 4\hat{i} - 3\hat{j}\) N and \(F_2 = -3\hat{i} + 4\hat{j}\) N. The third force is
Correct Answer: (a) \(-\hat{i} - \hat{j}\) N
For equilibrium, the sum of all forces must be zero. Thus, \(F_3 = -(F_1 + F_2) = -[(4-3)\hat{i} + (-3+4)\hat{j}] = -\hat{i} - \hat{j}\) N.
35. A plane is revolving around the earth with a speed of 100 km/hr at a constant height from the surface of earth. The change in the velocity as it travels half circle is
Correct Answer: (a) 200 km/hr
After half revolution, the velocity reverses direction. Change in velocity = final velocity - initial velocity = (-v) - v = -2v. Magnitude is 2v = 200 km/hr.
36. What displacement must be added to the displacement \(25\hat{i} - 6\hat{j}\) m to give a displacement of 7.0 m pointing in the x-direction
Correct Answer: (a) \(-18\hat{i} + 6\hat{j}\) m
Let required displacement be \(\vec{D}\). Then \(25\hat{i} - 6\hat{j} + \vec{D} = 7\hat{i}\). Solving gives \(\vec{D} = -18\hat{i} + 6\hat{j}\) m.
37. A body moves due East with velocity 20 km/hour and then due North with velocity 15 km/hour. The resultant velocity
Correct Answer: (d) 25 km/hour
Resultant velocity \( v = \sqrt{v_x^2 + v_y^2} = \sqrt{20^2 + 15^2} = \sqrt{400 + 225} = \sqrt{625} = 25 \) km/hour.
38. The magnitudes of vectors \(\vec{A}\), \(\vec{B}\) and \(\vec{C}\) are 3, 4 and 5 units respectively. If \(\vec{A} + \vec{B} = \vec{C}\), the angle between \(\vec{A}\) and \(\vec{B}\) is
Correct Answer: (a) \(\frac{\pi}{2}\)
Since \(3^2 + 4^2 = 5^2\), the vectors satisfy the Pythagorean theorem, meaning they are perpendicular (\(\theta = 90^\circ\) or \(\frac{\pi}{2}\) radians).
39. While travelling from one station to another, a car travels 75 km North, 60 km North-east and 20 km East. The minimum distance between the two stations is
Correct Answer: (b) 112 km
Calculate the net displacement: North component = 75 + 60cos45° ≈ 75 + 42.4 = 117.4 km; East component = 20 + 60sin45° ≈ 20 + 42.4 = 62.4 km. Minimum distance = \(\sqrt{117.4^2 + 62.4^2}\) ≈ 112 km.
40. A scooter going due east at 10 ms⁻¹ turns right through an angle of 90°. If the speed of the scooter remains unchanged in taking turn, the change in the velocity of the scooter is
Correct Answer: (d) 14.14 ms⁻¹ in south-west direction
Initial velocity \( \vec{v_i} = 10\hat{i} \) ms⁻¹, final velocity \( \vec{v_f} = -10\hat{j} \) ms⁻¹. Change in velocity \( \Delta \vec{v} = \vec{v_f} - \vec{v_i} = -10\hat{j} - 10\hat{i} \). Magnitude = \(10\sqrt{2}\) ≈ 14.14 ms⁻¹ in SW direction.
41. A person goes 10 km north and 20 km east. What will be displacement from initial point?
Correct answer: (a) 22.36 km
Displacement is the shortest distance between initial and final points. Using Pythagoras theorem:
\[ \text{Displacement} = \sqrt{10^2 + 20^2} = \sqrt{100 + 400} = \sqrt{500} \approx 22.36 \text{ km} \]
42. Two forces \( \vec{F_1} \) and \( \vec{F_2} \) act on a single point. The angle between \( \vec{F_1} \) and \( \vec{F_2} \) is nearly
Correct answer: (d) 90°
When two forces act at right angles, their resultant can be found using Pythagoras theorem. The given information suggests the forces are perpendicular.
43. Which pair of the following forces will never give resultant force of 2 N?
Correct answer: (d) 1 N and 4 N
The resultant of two forces must satisfy \( |F_1 - F_2| \leq R \leq F_1 + F_2 \). For option D, the possible range is 3N to 5N, which doesn't include 2N.
44. Two forces 3N and 2 N are at an angle θ such that the resultant is R. The first force is now increased to 6N and the resultant become 2R. The value of θ is
Correct answer: (d) 120°
Using the resultant formula \( R^2 = F_1^2 + F_2^2 + 2F_1F_2\cosθ \). When F₁ becomes 6N, the resultant becomes 2R. Solving these equations gives θ = 120°.
45. Three concurrent forces of the same magnitude are in equilibrium. What is the angle between the forces? Also name the triangle formed by the forces as sides
Correct answer: (a) 60° equilateral triangle
Three equal forces in equilibrium must be at 120° to each other (360°/3). When represented as sides of a triangle, they form an equilateral triangle with 60° between each side.
46. If \( \vec{A} + \vec{B} = \vec{C} \) and \( |\vec{A}| + |\vec{B}| = |\vec{C}| \), then angle between \( \vec{A} \) and \( \vec{B} \) will be
Correct answer: (c) 0°
When \( |\vec{A}| + |\vec{B}| = |\vec{C}| \), it means the vectors are collinear and pointing in the same direction, so the angle between them is 0°.
47. The maximum and minimum magnitude of the resultant of two given vectors are 17 units and 7 unit respectively. If these two vectors are at right angles to each other, the magnitude of their resultant is
Correct answer: (d) 13
Let the magnitudes be A and B. Then A + B = 17 and A - B = 7. Solving gives A = 12, B = 5. When perpendicular, resultant \( R = \sqrt{12^2 + 5^2} = 13 \).
48. The vector sum of two forces is perpendicular to their vector differences. In that case, the forces
Correct answer: (a) Are equal to each other in magnitude
If \( (\vec{A} + \vec{B}) \cdot (\vec{A} - \vec{B}) = 0 \), then \( |\vec{A}|^2 - |\vec{B}|^2 = 0 \), which implies \( |\vec{A}| = |\vec{B}| \).
49. y component of velocity is 20 and x component of velocity is 10. The direction of motion of the body with the horizontal at this instant is
Correct answer: (a) \( \tan^{-1}(2) \)
The angle θ with horizontal is given by \( \tanθ = \frac{v_y}{v_x} = \frac{20}{10} = 2 \), so \( θ = \tan^{-1}(2) \).
50. Two forces of 12 N and 8 N act upon a body. The resultant force on the body has maximum value of [Manipal 2003]
Correct answer: (c) 20 N
The maximum resultant occurs when forces act in the same direction: \( R_{max} = F_1 + F_2 = 12N + 8N = 20N \).
